Powerful pickup with convenience of crew cab and single cab

TATA YODHA CREW CAB

Tata Yodha is identified among the target audience as a muscular, powerful and robust pickup vehicle, equipped to carry higher payload and pull off faster turn-around owing to the powerful engine and strong aggregates. The brand resonates with the target audience’s desires for an ideal pickup vehicle – strong and agile, an anthropomorphism of a warrior. The new Tata Yodha BS6 range of Pickups are built on the promise of lower expenses, higher earnings.

Powered by the most powerful and fuel-efficient engine in the category, and the biggest cargo loading area, the Tata Yodha is one of the sturdiest and most stylish pickup range on Indian roads.

Available in both, single cab and crew cabin variants with 4x2 and 4x4 drive options, and with varied payload options of 2000 Kg, 1700 Kg, 1500 Kg and 1200 Kg, the Yodha Pickup range is built to seamlessly fit across multiple applications. Plus, its cabin chassis variant offers the flexibility of customized body options./p>

Tata Yodha Crew Cabin Features

Features designed for performance and profits

HIGH POWER

  • Tata Yodha range of pickups are equipped with most powerful engine in the segment, capable of generating 73.6 kW power and delivery 250 Nm torque, and hence are capable of carrying higher load and completing more number of trips on account of faster turn-around.

Superior Load Carrying Capability

  • Rigid semi-elliptical leaf spring suspension with 6 leaves on front and 9 leaves on rear side, and 4 mm thick hydroformed chassis frame, makes the vehicle suitable for carrying all kind of load in volumes and masses.
  • 16” big tyres enhances stability in high load condition and high speed operation.

High Fuel Economy

  • Eco mode and gear shift advisor for better fuel economy.

Low maintenance

  • Lubricated for life (LFL) aggregates requires no greasing throughout the vehicle life.
  • Engine oil change interval of 20,000 KMs – low vehicle service cost.
  • LNT technology with cDPF – no DEF filling required.

Enhanced Safety

  • Stone-guard on front end for enhanced safety.
  • Sturdy 3-piece metallic bumper for ease of repairs and serviceability.
  • Anti-roll bar on front side for stability on gradients and unleveled roads.

Superior Comfort

  • Superior driving ergonomics – adjustable power steering, reclining seat and ergonomic pedal position, for comfortable driving experience through long trips.
  • Flat laydown reclining seats with head rest
  • High utility compartments in the cabin – lockable glovebox, magazine/bottle holder.
  • Advanced features for additional convenience – fast mobile charger, RPAS and sliding window on cabin rear wall.

SPECIFICATIONS

Take an in-depth look at the technical specifications that make all the difference



Yodha Crew Cab 4x2

Yodha Crew Cab 4x4

Engine type

TATA 2.2L BS 6 DI engine (2179 cc)

Max engine output

 73.6 kW @ 3750 r/min

Max engine Torque

250 Nm@1000 -2500 r/min

Fuel tank capacity

45L

Clutch

Single Plate dry Friction type 260 mm Dia

Gearbox

GBS 76 - 5/4.49 Synchromesh 5F + 1R

Steering

Power Steering

Front suspension

Rigid Suspension with leaf spring & Shock absorber

Rear suspension

Semi-elliptical type with Hydraulic Double Acting Telescopic Shock Absorber

Anti-Roll Bar

Front

Front brakes

Hydraulic, twin pot Disc Brake

Rear brakes

Drum Brakes

Tyre

215/75 R 16 Radial tubeless

215/75R 15 LT

Rim size

16"

15"

External Load body (mm)

1880 x 1850

Turning Circle Radius (mm)

6250

Overall Vehicle Dimensions

Wheel Base (mm)

3150

3150

Width (mm)

1860

1860

Length (mm)

5350

5350

Height (mm)

1810

1810

Ground Clearance (mm)

210

190

Weights (kg)

GVW (Kg)

2990

2990

Kerb weight (Kg)

1850

1930

Payload (Kg)

1140

1060

Performance

Gradability

40%

30%

Warranty Terms

Engine Oil change interval

20 000 km

20 000 km (10,000 kms for Hilly & off road conditions)

Warranty (On Driveline)

3 Years/3 Lac kms

3 Years/3 Lac kms

Tata Yodha Crew Cab Gallery
